Rudyard Lake & Rudyard Railway station Staffordshire . the UK.
Rudyard railway station served Rudyard, Staffordshire and was opened by the North Staffordshire Railway (NSR) in 1850 on the Churnet Valley line. In the village the NSR also owned the Rudyard Hotel as part of the company's efforts to develop Rudyard Lake and its environs as a tourist destination.
In 1926 the London, Midland and Scottish Railway renamed the station Rudyard Lake and at the same time Rudyard Lake station at the north end of the lake was renamed Cliffe Park.
As Rudyard Lake station, it remained open until passenger services were withdrawn from the northern end of the Churnet valley line (North Rode – Leek) in 1960. Freight services lasted until 1964 when they too were withdrawn and the track lifted.
In 1978 a miniature railway was built on the west side of the trackbed from Rudyard Station to the Dam. This closed two years later and was moved to the Suffolk wildlife park. and then to Trago Mills in Devon. One of the locomotives, a model of the Leek and Manifold Valley Light Railway engine No.1 E. R. Calthrope now periodically revisits the current railway at Rudyard.
A further 10.25 inches (26.0 cm) minimum gauge railway was started in 1985 and extended to a distance of 1.5 miles (2.4 km) towards Cliffe Park station. Today the station area is used by the Rudyard Lake Steam Railway as its headquarters and as a public car park. Rudyard station now includes engine and carriage sheds, workshop, signal box, footbridge, the Platform 2 café and a level crossing. The railway has five steam locomotives and 11 carriages and a number of wagons and operates year round. This railway celebrated its 25th anniversary in 2010.
The original up side standard gauge platform and retaining walls and flower beds are still visible. The Platform 2 cafe now uses this area for its seating and the original waiting shelter foundations for its buildings.
The Rudyard Lake Steam Railway is a ridable miniature railway and the third railway of any gauge to run along the side of Rudyard Lake in Staffordshire. The railway runs for 1 1⁄2 miles (2.4 km) on the track bed of an old standard gauge North Staffordshire Railway line. After the NSR line closed down, a small narrow gauge train ran on the site for two years before moving via Suffolk to Trago Mills in Devon. The current line started in 1985 and is 10 1⁄4 in (260 mm) gauge, and operates to a timetable. It was built by Peter Hanton of Congleton working on his own over a period of 10 years. He sold the railway to the Rudyard Lake Steam Railway Ltd in October 2000 who have developed it since that date.
Trains are about half the size a normal narrow gauge railway and are steam hauled. The railway runs from Rudyard railway station to the Dam then along the side of the lake to terminate by the lakeside at Hunthouse Wood. This is about a mile South of the site of the old Cliffe Park railway station. The Railway was purchased by the Leek and Rudyard Railway on 18th December 2015. This company owns the assets of the former Mull Railway and has plans to combine the two railways at Rudyard.
Trains run on Sundays and Bank Holidays from January to the end of November, with more regular services from Easter to October and daily during school holidays. The railway is a member of Britains Great Little Railways and was a member of the Heritage Railway Association.
Rudyard Lake Steam Railway
Legend
end of line 1800 m
Hunthouse Wood Station 1750 m
Crossing point
Dam Station 500 m
107 m
LC 50 m
Rudyard Station 0m
to sheds
Locomotives
Pendragon
It has six steam locomotives, mostly named by the former owner's wife after the legends of King Arthur:
№ Name Wheel arrangement Builder Date built Notes
6 Excalibur 2-4-2T Exmoor Steam Railway 1993 Previously named River Churnet prior to rebuild in 2003
7 Merlin 2-4-2T Exmoor Steam Railway 1998
8 King Arthur 0-6-2T Exmoor Steam Railway 2005
9 Pendragon 2-4-2T Exmoor Steam Railway 1994 Previously named Ashorne from Ashorne Hall Railway
196 Waverley 4-4-2 David Curwen 1948 On permanent loan from a group linked to the Isle of Mull Railway
- Victoria 2-6-2T Mouse Boiler Works 1993 Based on scaled-down Victorian Railways NA class.Victoria is owned by the Leek & Rudyard Railway Ltd who also owns all the closed Isle of Mull railway along with diesel loco's Frances and Glen Audlyn. Victoria ran regularly at Rudyard until Autumn 2015. She was removed for overhaul in Sheffield on 22 December 2015 and will return after completion of the work.
Merlin runs along the side of Rudyard Lake
There is also :
A 4 Wheel Petrol Loco № 2 Modred (also known by the volunteers, as the Ferret)
A 4W+4W bogie diesel loco. № 5 Rudyard Lady
A 2-2-2 battery electric loco. № 3 Sir Ernie (departed to a private owner in 2015)
A 4W+4W bogie diesel loco. Glen Auldyn, from the closed Isle of Mull Railway
A 4W=4W bogie diesel loco Frances, from the closed Isle of Mull Railway
These are normally only used for maintenance although even for these duties the railway is now using its steam locomotives year round in preference to locomotives powered by internal combustion engines as they are proving more economical and reliable.
Visiting steam locomotives often attend the annual steam gala held each year over a weekend in late September. The 2011 guest locomotive was Victoria from the closed Isle of Mull railway which remains at Rudyard and is used sometimes on normal services.
A fleet of 13 carriages and a wide variety of goods wagons are also used. A further enclosed brake carriage was constructed in 2011 and brought into service in August and another 12 seat enclosed coach added in December 2012.
Facilities
File:RudyardLake.ogv
"Merlin" coupling up at Rudyard station in 2013
Rudyard Station comprises Platform 1 with a shelter where the trains depart. A footbridge links this to Platform 2 where the cafe, a large covered picnic area, signal box and toilets are located. Platform 2 is in fact the original standard gauge platform built by the North Staffordshire Railway. The original flower beds and retaining walls are clearly visible. At a higher level than platform 1 its a good vantage point. To the South end of the station are the engine shed, water tower, coal bunker, storage shed and workshop.
The railway offers learn to drive a steam train courses, of either a half or full day for individuals or groups. Children's parties are hosted and the Platform 2 Cafe provides hot and cold refreshments all year around whenever the railway is running.
References
Hanton. Peter The Heywood Society Journal № 34 Spring 1994
Williams John K. The Heywood Society Journal № 52 Spring 2003
Hanson Michael The Heywood Society Journal № 56 Spring 2005
